Cold Drawn Carbon Steel Pipe

Name: Cold Drawn Carbon Steel Pipe
Rating: 5.0 (31 reviews)

Availability:

Quantity:



Inquire Add to Basket

Product Description

Product Name	Carbon Steel Pipe
Production Standards & Materials	API 5L/ASTM A106/A53 Grade A,B,C,D
	ASTM SA179/178/SA192
	EN10216-1 P195TR1/TR2, P235TR1/TR2, P265TR1/TR2
	EN10216-2 195GH,P235GH,P265GH,TC1,TC2
	DIN17175 ST35.8, ST45.8
	JIS G3454 STPG370, STPG410
	JIS G3461 STB340, STB410, STB440
Outside Diameter Ranges	15mm-219mm
Wall Thickness Ranges	1mm-15mm
Length (negotiable)	5.8m
	6m,12m,14m
	As per request
Pipe Type	Cold Drawn
Pipe End	1> 8-60mm Plain End; 2> 60-168.3mm Plain End or Beveled End
End protector	1> Plastic pipe cap; 2> Steel Socket
Packing	Seaworthy packing(bundled according to the different size), with plastic bags or plywood box.
Out Surface Treatment	Bared, Black Painted, Varnish, Oil-dip, Passivation, Phosphating, Shot blasting
Inspection	With Hydraulic Testing, Eddy Current, Infrared Test
Application	Low-Pressure Liquid, Water, Gas, Oil, Line Pipe, Heat-Transfer Equipment, such as tubular heat exchanger, condenser and superheater, For high, middle, low-pressure boiler and pressure purpose
Our advantages	·Diverse products(Steel pipes, pipe fittings)
	·Any third party inspection can be accepted
	·Quick response for quotation, delivery, after-service.
	·Focus on pipe & tube solution for project application.

Carbon Steel Cold Drawn Welded Pipe
