Aluminum Foil / Air Conditioner Foil 3102 8011 8006

Name: Aluminum Foil / Air Conditioner Foil 3102 8011 8006
Rating: 5.0 (2 reviews)

Availability:

Quantity:



Inquire Add to Basket

Product Description

1. Characteristics

Product	Grade	Temper	Thickness mm	Width mm	Surface
Double Zero Foil	1235 1145 8011 8079	H18 O	0.006-0.009	200-1700	One side bright
Household Foil	1235 8011 1145	O	0.009-0.02	200-1700	One side bright
Pharmacy Foil	1235 8011	H18	0.009-0.03	200-1700	One side bright
Container Foil	3003 8011 8021	H22 H24 O	0.04-0.2	200-1700	Two sides bright
Beer Mark Foil	1235 8011	O	0.009-0.011	200-1700	One side bright
Air Conditioner Foil	3102 8011 8006	O H22 H24	0.08-0.15	200-1700	Two sides bright
Food Soft Packing Foil	8011 1235 1145	O	0.009-0.023	200-1700	One side bright

2. production standard :as per international standard ASTM OR EN standard ,
all chemical composition ,mechanical property ,size tolerance ,flat tolerance ,etc strictly as per ASTM OR EN standard

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Other		Al
Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Single	Total	Al
1050	0.25	0.4	0.05	0.05	0.05	_	0.05	0.03	0.03	_	≥99.5
1060	0.25	0.35	0.05	0.03	0.03	_	0.05	0.03	0.03	_	≥99.6
1100	Si+Fe:0.95		0.05~0.40	0.05	_	_	0.1	_	0.05	0.15	≥99
1200	Si+Fe:1.00		0.05	0.05		_	0.1	0.05	0.05	0.15	≥99
3003	0.6	0.7	0.05~0.20	1.0~1.5	_	_	0.1	_	0.05	0.15	Remainder
3105	0.6	0.7	0.3	0.30~0.8	0.20~0.8	0.2	0.4	0.1	0.05	0.15	Remainder
5005	0.3	0.7	0.2	0.2	0.50~1.1	0.1	0.25	_	0.05	0.15	Remainder
5052	0.25	0.4	0.1	0.1	2.2~2.8	0.15~0.35	0.1	_	0.05	0.15	Remainder
5083	0.4	0.4	0.1	0.40~1.0	4.0~4.9	0.05~0.25	0.25	0.15	0.05	0.15	Remainder
5086	0.4	0.5	0.1	0.20~0.7	3.5~4.5	0.05~0.25	0.25	0.15	0.05	0.15	Remainder
6061	0.4~0.8	0.7	0.15~0.40	0.15	0.80~1.20	0.04~0.35	0.25	0.15	0.05	0.15	Remainder
6063	0.2~0.6	0.35	0.1	0.1	0.45~0.90	0.1	0.1	0.1	0.05	0.15	Remainder
6082	0.7~1.3	0.5	0.1	0.4~1.0	0.6~1.2	0.25	0.2	0.1	0.05	0.15	Remainder
8011	0.5~0.9	0.6~1.0	0.1	0.2	0.05	0.05	0.1	0.08	0.05	0.15	Remainder

Aluminum Foil Air Conditioner A3102 A8011 A8006
