Our forged steel flanges are manufactured in accordance with international standards and are widely used in piping systems for oil & gas, petrochemical, power generation and industrial applications.
We supply a full range of standard and non-standard flanges, including welding neck, slip on, blind, threaded and special flanges, with sizes from DN15 to DN3000.
| Standard System | Specifications |
|---|---|
| ANSI / ASME | ASME B16.5, MSS SP-44, API 605, AWWA C207, BS 3293 |
| DIN | DIN 2631, 2632, 2633, 2634, 2635, 2636, 2637; DIN 2573, 2576, 2527, 2566; DIN 2642, DIN 2655 |
| UNI | UNI 2276, 2277, 2278; UNI 6082, 6083, 6084, 6088, 6089, 6090; UNI 2280, 2281, 2282, 2283, 2284, 6085, 6086; UNI 6091, 6092, 6093, 6094, 6095, 6096, 6097, 6098, 6099; UNI 2253, 2254 |
| BS | BS 4504 PN10, PN16, PN25, PN40; BS 10 Table E / Table D |
| JIS | JIS B2220 5K, 10K, 16K, 20K, 30K, 40K |
| EN | EN 1092-1 PN10, PN16, PN25, PN40 |
| Material Category | Material Grade |
|---|---|
| Carbon Steel | ASTM A105; ASTM A350 LF1, LF2, LF3; C22.8; C21; RST37-2; SS400; SF450A; 20Mn; Q235; 20# |
| Alloy Steel | ASTM A182 F9, F11, F22; ASTM A694 F42-70; 15CrMo |
| Stainless Steel | ASTM A182 F321, F304, F304L, F316, F316L, F316Ti, F51, F65; DIN 17440 1.4541, 1.4571, 1.4301, 1.4401, 1.4406; SUS 304, SUS 304L, SUS 316, SUS 316L |
Welding neck flanges feature a long tapered hub that provides smooth stress distribution and strong structural integrity. They are commonly used in high-pressure and high-temperature pipeline systems.
Slip on flanges are easy to install by slipping the pipe into the flange bore and welding it in place. They are widely used in low-pressure applications where easy alignment is required.
Blind flanges are used to close the end of a piping system or pressure vessel. They provide easy access for inspection and maintenance and are suitable for various pressure ratings.
Threaded flanges are designed with internal threads and can be installed without welding. They are typically used in low-pressure and non-critical piping systems.
Socket weld flanges are designed for small-diameter, high-pressure piping. The pipe is inserted into the socket and welded, providing a strong and leak-resistant connection.
Orifice flanges are used together with orifice plates to measure flow rate in piping systems. They are commonly applied in oil, gas and chemical industries.
Spectacle blinds consist of a solid plate and a spacer connected by a web. They are used to isolate sections of a pipeline for safety and maintenance purposes.
Anchor flanges are designed to restrict axial movement in pipeline systems. They are commonly used in long-distance pipelines and high-pressure applications to absorb thrust forces.
| Item | Specification |
|---|---|
| Pressure Rating | Class 150 – 2500 / PN6 – PN400 |
| Size Range | DN15 – DN3000 |
| Item | Specification |
|---|---|
| Custom Products | Flanges and forgings according to customer requirements and drawings |
| Maximum Outer Diameter | Below 5000 mm |
| Maximum Weight | Less than 15 tons |
Anti-rust treatment
Painting
Oiling
Galvanizing
Forged steel flanges are widely used in oil and gas pipeline systems for connecting pipes, valves and equipment. Their high strength and pressure resistance make them suitable for demanding operating conditions.
In petrochemical and chemical plants, forged flanges are applied in processing units and pipelines where reliability, corrosion resistance and compliance with international standards are required.
Forged steel flanges are commonly used in power generation equipment, including boilers, turbines and auxiliary piping systems, supporting stable operation under high temperature and high pressure.
These flanges are essential components in industrial piping systems and pressure vessels, providing secure and leak-resistant connections for various industrial processes.
Forged steel flanges are also used in water treatment facilities and offshore projects, where durability and long service life are critical under corrosive and harsh environments.
Custom flanges can be manufactured according to customer drawings or specific technical requirements, including dimensions, materials and applicable standards.
We support the production of non-standard flanges and special forgings to meet unique application needs, including large-size and special-structure products.
Our manufacturing capability supports bulk orders and long-term supply projects, ensuring stable quality, consistent specifications and reliable delivery.
OEM services and project-based manufacturing are available to support engineering projects, EPC contractors and industrial customers with customized solutions.
Our forged steel flanges are manufactured according to international standards such as ASME, DIN, EN, JIS, BS and UNI, and can also be produced to meet specific customer requirements.
We supply forged flanges in carbon steel, alloy steel and stainless steel, including ASTM, DIN and SUS material grades to suit different pressure and temperature conditions.
Yes. We can manufacture non-standard flanges and special forgings according to customer drawings or technical specifications, including large-size and special-structure products.
Our forged flanges are available in pressure ratings from Class 150 to Class 2500 and PN6 to PN400, with sizes ranging from DN15 to DN3000.
Yes. We support bulk orders and long-term supply projects with stable production capacity, consistent quality control and reliable delivery schedules.
